Folder Gluer Inspection Machine

• Box folding gluing and quality inspection finish at the same time and then remove the rejected sheet;
• Set inspection tolerance according to different detect zones ensure quality and quantity;
• Dynamically tolerance setting and have regional self-learning function easy to make little adjustment;
• Testing data automatic storage and classification easy for data searching;
• Box folding gluing and quality inspection finish at the same time;
• The printed side is face down when feeding sheet effectively avoid secondary scratch;
• It can be used as an independent inspection machine or add it on your folder gluer without modify your press;
• It can detect the overall informationincluding printing quality of both side die cutting and supervision code etc;
• Easy software design enable the operators mastered the operation skills within two hours;
• Switching new job takes no more than 2 minutes;
Quantity:
  • UPG-5
  • UPG
Item HX650-woodpecker HX850-woodpecker HX1100-woodpecker HX1450-woodpecker
(mm)
Max Sheet Width
650*500 800*600 1100*750 1450*750
(mm)
Min Sheet Width
100*80 100*100 300*300 300*300
(mm)
Max Inspection Format
600*500 800*600 1000*750 1350*750
(m/min)
Feed Speed
300 200 180 180
(m/min)
Max Inspection Speed
250 180 160 160
(g/m2)
Paper Weight Range
90~350 90~350 200g-350 200g-350
(mm2)
Min Inspection Resolution
0.15 0.1 0.2 1.3
Min Color Variation Defects  E ≥ 3  E ≥ 3  E ≥ 3  E ≥ 3
mm
Misregister
±0.1 ±0.1 ±0.1 ±1
mm
Die Cutting Deviation
±0.8 ±0.6 ±0.8 ±1.5
Severe Defects Inspection Repetition code,
defective code,
missing characters
Repetition code,
defective code,
missing characters
Repetition code,
defective code,
missing characters
/
Supervision Code Printing
Quality Inspection
Defective line,
smear and missing
Defective line,
smear and missing
Defective line,
smear and missing
/
Printing Quality Inspection smear, pasting plate,
fringe, bite, ink dots,
holes, mosquito and
oil dots, hot stamping,
belling,etc
smear, pasting plate,
fringe, bite, ink dots,
holes, mosquito and oil
dots,etc
smear, pasting plate,
fringe, bite, ink dots,
holes, mosquito and oil
dots,etc
smear, pasting plate,
fringe, bite, ink dots,
holes, mosquito and oil
dots,etc
Machine Size 7400mm(L)x1450mm(W)
x1600mm(H)
7400mm(L)x1650mm(W)
x1600mm(H)
6400mm(L)x1900mm(W)
x1600mm(H)
6400mm(L)x2200mm(W)
x1600mm(H)
Bottom Area 7400mm(L)x3300mm(W)
x1600mm(H)
7400mm(L)x3500mm(W)
x1600mm(H)
9000mm(L)x1900mm(W)
x1600mm(H)
9000mm(L)x2200mm(W)
x1600mm(H)
Net Weight 3t 3.5t 5.5t 6.5t
Machine Power 20KW 22kw 17kw 19kw
Inspection Station Surface Inspection
station: 1 camera,the
resolution isw*h
0.133*0.136
Gold stamping
inspection station: 1
camera, the resolution
isw*h0.133*0.136
Surface Inspection
station: 2 cameras,the
resolution is w*h
0.11*0.11
Surface Inspection
station: 2 cameras,the
resolution isw*h
0.135*0.135
Surface Inspection
station: 2 cameras,the
resolution isw*h
0.35*0.35



image1image2image3image4image5image6

image7image8
