LQ-MD 350 UV Coating Machine

  • LQ-MD 350 UV Coating Machine
  • UPG
  • LQ-MD 350 UV Coating Machine

1. High Integration
Equipped with Ultrasonic correction device, Rewinding & Unwinding, Constant tension of anti-film
magnetic powder, Variable Speed regulation and UV Curing system.

2. Flat & Average UV Coating
The UV coating liquid leveling is between 0.3m~1.2m makes the coating surface smoother.
By using customized Anilox roller, the coating thickness could be flexibly adjusted and controlled.

3. Multiple Functions

· UV coating
· UV curing
· UV laser film transfer
· UV gluing lamination
· De-adhesive (Erasing adhesive between layers)
· Bottom layer material changing

ModelLQ-MD 350
Feeding width350mm
Maximum coating width340mm
Running speedUp to 70m/min (depends on the thickness of media)
UV curing power7000W
Mechanical dimensions2000*1700*1000mm

UV   Coating

1   set

Uitrasonic   Correcting Device

1   set

Tension   Controller

4   sets

Expanding   Air Shaft

4   pieces

UV   Curing System (Mercury lamp)

1   set

Anilox   Roller (Mesh optional)

1   piece
