NOVA10 (6+1)
LQ
NOVA10 (6+1) Combined Saddle Stitching Line
We have developed the proven PURLUX saddle stitching Line. Essential improvements and ideas of our customers are included into the new NOVA 10 STITCHER. With even shorter make ready time, the NOVA 10 STITCHER is the best choice for printers and binderies in the 10,000 c/h class. We have retained the strong principle features of our feeder design but improved the performance of the gripper system by strong gripper design and addition of low wear synthetic gripper pads, thus increasing the retention forces of the gripper system. The cover folder feeder has now two scoring positions. In the stitching section the reject collection tray and adjustment devices are now accessible from below, which makes adjustment of the trimming in feed much easier. The newly designed trimmer is typified by easy operation and quick exchange of optional devices. A trim waste removal belt is integrated into the new trimmer.
Technical Specifications:
Max. Format (Untrimmed) | 450×311mm |
Max. Format (Trimmed) | 440×300mm |
Min. Format (Untrimmed) | 158×100mm |
Min. Format (Trimmed) | 148×75mm |
Max.Center cut (trimmed) | 2×217×300mm |
Min.Center cut (trimmed) | 2×95×105mm |
Product Thickness Normal Stitch | max. 8mm |
Product Thickness Loop Stitch | max. 3mm |
Number of standard Stitching Heads | max. 6 Hohner M45/6 |
Number of loop Stitching Heads | max. 4 Hohner M55/L |
Max. Mechanical Speed | 10000 c/h |
Power Consumption (standard equipments) | 20kW |
Liner Delivery | 0.5kW |
Drive Power for the saddle Stitcher till 14 feeders | 7.5kW (without air pump) |
Drive Power ever air pump 80cbm | 4.0kW |
