LQ-100
LQ
Suitable for various laminated films.
All the parameters are diaplayed in CRT real time. The speed, bag length, temperature, counting, punching, multiplying delivery and delivery amount of finished products, etc, can be pre-set.
Automatic alarm for unwinding tension, middle tension, color sign loss and super-high temperature.
Bag-length is controlled by AC servo-system.
LPC deviation correction for paying-off , automatic control of tension.
Multi-functional punching, static electricity removal.
Suitable for various laminated films.
All the parameters are diaplayed in CRT real time. The speed, bag length, temperature, counting, punching, multiplying delivery and delivery amount of finished products, etc, can be pre-set.
Automatic alarm for unwinding tension, middle tension, color sign loss and super-high temperature.
Bag-length is controlled by AC servo-system.
LPC deviation correction for paying-off , automatic control of tension.
Multi-functional punching, static electricity removal.
Specification | LQ-100 |
Material | PE,PP,EVA,ABS,PS… |
Max container capacity | 50L |
Output(dry cycle) | 300*2pc/hr |
Machine Dimension(LxWxH) | 6400*6400*4000M |
Total weight | 20T |
Clamping Unit | |
Clamping force | 200KN |
Platen opening stroke | 350-850MM |
Platen size(WxH) | 850*800MM |
Max mould size(WxH) | 590*700MM |
Mold thickness | 360-500MM |
Extruder unit | |
Screw diameter | 100MM |
Screw L/D ratio | 28L/D |
Melting capacity | 160KG/HR |
Number of heating power | 28KW |
Extruder heating power | 5 Zone |
Extruder driving power | 45KW |
Die head | |
Number of heating zone | 5 Zone |
Power of die heating | 18 KW |
Max die-pin diameter | 260 MM |
Power | |
Max drive | 42 KW |
Total power | 120 KW |
Fan power for screw | 4 KW |
Air pressure | 0.8 Mpa |
Air consumption | 0.8 m³/min |
Average energy consumption | 45 KW |
Accumulator capacity | 10 L |
