LQ-FL
UPG
Main Applications:
The machine is widely used for the operations of mixing, granulating and drying of granules and powders materials in pharmaceutical, food and chemical industries. For example, granules for tablet, granules for quick-resolving drinking, and condiment.
Main Features:
1. Control system is PLC & Touch screen type, operation is convenient and stable. There is strict interlock function, so there will be no incorrect operation. There are temperature and pressure measure and display devices, inlet air temperature is controlled by PID control technology.
2. Application range is wide, it can dry different materials, and it can ensure the definite fluidized height so that the load of bag dust collector is reduced. The bag dust collector can remove dust continuously when the granulator dryer is working.We can set dust remove time and interval time, so the dust removing efficiency and fluidized efficiency is good. The bag is static-free type, the static electricity appears during the granulating and drying process can be eliminated, so the material isn’t to stick on the bag. There is differential pressure display device for the bag, so we can clean or replace the bag in time.
3. Air volume of the drying system is controlled by exhaust fan, and the exhaust fan is controlled by inverter. So it is convenient to adjust the air volume for different materials.
4. The equipment is round sealed structure, there is no dead angle. So it is convenient to clean the machine and there is no cross contamination. It meets the requirements of GMP.
5. The air distributing plate is special designed, air is well-distributed, material fluidized efficiency is good. Mesh plate is quick-install type, it is convenient to clean and maintain.
6. There is negative pressure feed device, labor intensity is reduced.
7. Adopts air cylinder type sealing and air bag sealing structure, seal is stable and operation is easy.
8. Filter includes primary, middle and high efficient filter. It can make sure the purification achieves 100000 degrees. And there is a meter that can show the pressure differential before and after the high efficient filter, so we can know the resistance in time.
9. Heating source is steam, material of steam radiator is stainless steel. User can use proportional control valve to control the flow of steam, and the temperature differential is controlled within ±2℃ by PID technology.
Main Applications:
The machine is widely used for the operations of mixing, granulating and drying of granules and powders materials in pharmaceutical, food and chemical industries. For example, granules for tablet, granules for quick-resolving drinking, and condiment.
Main Features:
1. Control system is PLC & Touch screen type, operation is convenient and stable. There is strict interlock function, so there will be no incorrect operation. There are temperature and pressure measure and display devices, inlet air temperature is controlled by PID control technology.
2. Application range is wide, it can dry different materials, and it can ensure the definite fluidized height so that the load of bag dust collector is reduced. The bag dust collector can remove dust continuously when the granulator dryer is working.We can set dust remove time and interval time, so the dust removing efficiency and fluidized efficiency is good. The bag is static-free type, the static electricity appears during the granulating and drying process can be eliminated, so the material isn’t to stick on the bag. There is differential pressure display device for the bag, so we can clean or replace the bag in time.
3. Air volume of the drying system is controlled by exhaust fan, and the exhaust fan is controlled by inverter. So it is convenient to adjust the air volume for different materials.
4. The equipment is round sealed structure, there is no dead angle. So it is convenient to clean the machine and there is no cross contamination. It meets the requirements of GMP.
5. The air distributing plate is special designed, air is well-distributed, material fluidized efficiency is good. Mesh plate is quick-install type, it is convenient to clean and maintain.
6. There is negative pressure feed device, labor intensity is reduced.
7. Adopts air cylinder type sealing and air bag sealing structure, seal is stable and operation is easy.
8. Filter includes primary, middle and high efficient filter. It can make sure the purification achieves 100000 degrees. And there is a meter that can show the pressure differential before and after the high efficient filter, so we can know the resistance in time.
9. Heating source is steam, material of steam radiator is stainless steel. User can use proportional control valve to control the flow of steam, and the temperature differential is controlled within ±2℃ by PID technology.
Model | Unit | 3 | 5 | 15 | 30 | 60 | 120 | 200 | |
Volume of Material Container | L | 12 | 22 | 45 | 100 | 220 | 420 | 670 | |
Capacity | Kg/batch | 3 | 5 | 15 | 30 | 60 | 120 | 200 | |
Steam | Pressure | Mpa | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
Consumption | Kg/h | 15 | 23 | 42 | 70 | 140 | 211 | 282 | |
Power of Fan | kw | 3 | 4 | 5.5 | 7.5 | 11 | 18.5 | 22 | |
Noise | dB | <75 | <75 | <75 | <75 | <75 | <75 | <75 | |
Compressed Air Consumption | m3/min | 0.6 | 0.6 | 0.6 | 0.9 | 0.9 | 0.9 | 1.1 | |
Temperature | ℃ | Normal temperature-120 ℃ automatic adjustment | |||||||
Operation Time | min | 45-90(depend on the material) | |||||||
Material Yield | ﹪ | ≥99 | |||||||
Proportion of Adhesive | Kg/L | <1.25 | |||||||
Height of Main Machine | mm | 1800 | 2100 | 2200 | 2300 | 3000 | 3300 | 3800 | |
Final Moisture Content | ﹪ | Up to 0.2﹪ |
