This product is mainly used to singly and continuously dry the 200L, 210L steel barrel or other small sized steel barrel for bottom and top cover drying. The product line is furnished with pre-transmission, feeding, front exhaust, drying tunnel, heating system, rear exhaust, cooling, rear-transmission, wicket and the conveying system etc.
The main heating source can be electricity, coal gas, LPG, natural gas, kerosene, diesel oil, coat-fired convection oven may be used, too.
The main chain is pneumatically tensioned.
The wicket is employed to support the conveying system of the barrel cover.
This product is characteristic with high efficiency in the production and easy operation. The inverter is adopted to control the conveying speed.
Max. size of the applicable barrel cover | ¢680mm |
Min. size of the applicable barrel cover | ¢260mm |
Max. weight of the barrel cover | 4kg |
Max. productivity | 800(p/h) |
Length of the baking path | 18m |
Process temperature | 120~240(℃) |
Length of the cooling section | 4.63m |
