LQ-MD1200 Sheet Metal Auxiliary Feeder

Continous stacker is an auxiliary equipment for metal sheet printing & coating machine, waxing machine and inkjet printer etc, it is used for sheet collecting, sheet automatically fal, roller way output and other functions. Because the usage of a dua-switch receipt, to achieve the continuous production equipment to achieve energy eficiency and improve work efficiency purposes.
Availability:
Quantity:
Inquire Add to Basket

PDF Export
LQ-MD1200 Sheet Metal Auxiliary Feeder

  • LQ-MD1200

  • UPG

Continous stacker is an auxiliary equipment for metal sheet printing & coating machine, waxing machine and inkjet printer etc, it is used for sheet collecting, sheet automatically fal, roller way output and other functions. Because the usage of a dua-switch receipt, to achieve the continuous production equipment to achieve energy eficiency and improve work efficiency purposes.

·The distance between the wooden pallet and the conveyer belt can be adjusted by the left and the right, so as to adapt of different sizes pallet.
·With the main feeder switch using photoelectric detection PLC control, automatic switching.
·With wooden pallet storage function, the use of forklits and other tools to carry wooden pallet, less labor work;
·The car can move forward and backward stroke limit position switch control, safe and reliable.
·The roller conveyor individual control. which can be easy operation.
·Touch screen operation is convenient.
·Can be maintained in the stop station, large maintenance space


Maximum Metal Sheet Size1143x930 mm
Minimum Metal Sheet Size712x508 mm
Thickness of Metal Plate0.16~0.5 mm
Cylinder SizeΦ 254x1180 mm
Rubber Roller SizeΦ 356x1155 mm
Upper Duct Roller SizeΦ 203.22x1150 mm
Lower Duct Roller SizeΦ 203.22x1150 mm
Productivity4800 p/h
Machine Weight3100 kg


download Sheet Metal Printing and Coating Machines.pdf
