Availability: | |
---|---|
LQ-CS1450-2250
UPG
It is suitable for eco-friendly packaging, such as the paper bag used for food and healthcare industry, paper box, paper cup, the pre-printing carton of paper bag, bag courier, milk carton medicine use.
Main Feature
Petal type plate mounting, anilox and cylinder with quick change structure.
Printing unit easy operation, cylinder and anilox pressing once successfully.
Plate full servo shaftless transmission, automatically pre-print, time saving&material saving.
Registering remains the same during lifting process.
Register position automatic memory function.
It is suitable for eco-friendly packaging, such as the paper bag used for food and healthcare industry, paper box, paper cup, the pre-printing carton of paper bag, bag courier, milk carton medicine use.
Main Feature
Petal type plate mounting, anilox and cylinder with quick change structure.
Printing unit easy operation, cylinder and anilox pressing once successfully.
Plate full servo shaftless transmission, automatically pre-print, time saving&material saving.
Registering remains the same during lifting process.
Register position automatic memory function.
Specification | 1000 | 1270 | 1350 |
Max. web width | 1020mm | 1300mm | 1350mm |
Max. printing width | 1000mm | 1270mm | 1320mm |
Max. die cutting width | 1000mm | 1270mm | 1320mm |
Printing repeat length | 300-1000mm | ||
Max. unwinder dia. | 1524mm/1200mm | ||
Max. rewinder dia. | 1524mm/1200mm | ||
Gearing | 1/8cp | ||
Max. printing speed | 240m/min | ||
Base motor power | 22kw | 22kw | 30kw |
Drying mode | a. hot air drying b.IR drying c.UV drying | ||
Material | 80-450g chrome paper, aluminium-foil paper, bopp PET and paper board,. kraft paper |
Specification | 1000 | 1270 | 1350 |
Max. web width | 1020mm | 1300mm | 1350mm |
Max. printing width | 1000mm | 1270mm | 1320mm |
Max. die cutting width | 1000mm | 1270mm | 1320mm |
Printing repeat length | 300-1000mm | ||
Max. unwinder dia. | 1524mm/1200mm | ||
Max. rewinder dia. | 1524mm/1200mm | ||
Gearing | 1/8cp | ||
Max. printing speed | 240m/min | ||
Base motor power | 22kw | 22kw | 30kw |
Drying mode | a. hot air drying b.IR drying c.UV drying | ||
Material | 80-450g chrome paper, aluminium-foil paper, bopp PET and paper board,. kraft paper |
