LQ-DB1500
UPG
This machine is used for binding double wire books, notebooks, calendars etc. With the integration of automatic cutting, loops-counting, skip binding and closing, it increases the production efficiency and reduces the cost remarkably. It’s your best choice for double wire binding.
1) The machine is designed for normal wire and paper, with a high reliability and low loss.
2) Various loops diameters can be processed by changing the individually closing moulds. It’s easy and fast.
3) The machine is made up of double wire forming machine and double wire binding machine, it increases the production efficiency and reduces the cost remarkably.
4) Optional hanger attachment is available.
This machine is used for binding double wire books, notebooks, calendars etc. With the integration of automatic cutting, loops-counting, skip binding and closing, it increases the production efficiency and reduces the cost remarkably. It’s your best choice for double wire binding.
1) The machine is designed for normal wire and paper, with a high reliability and low loss.
2) Various loops diameters can be processed by changing the individually closing moulds. It’s easy and fast.
3) The machine is made up of double wire forming machine and double wire binding machine, it increases the production efficiency and reduces the cost remarkably.
4) Optional hanger attachment is available.
Size | pitch | Back ground(mm) | Wire dia(mm) | Binding thickness(mm) | Binding page(page) |
1/4 | 3:1 | 4.0x4.0 | 6.4 | 4.9 | 45 |
5/16 | 3:1 | 4.0x4.0 | 7.9 | 6.3 | 60 |
3/8 | 3:1 | 4.0x4.0 | 9.5 | 7.9 | 70 |
7/16 | 3:1 | 4.5x4.5 | 11.1 | 9.3 | 85 |
1/2 | 3:1 | 4.5x4.5 | 12.7 | 10.9 | 100 |
9/16 | 3:1 | 4.5x4.5 | 14.3 | 12.2 | 120 |
5/8 | 2:1 | 5.0x5.0 | 15.9 | 13.4 | 130 |
3/4 | 2:1 | 5.0x5.0 | 19.1 | 16.6 | 160 |
Speed | 1500 Volume/hour |
Air Pressure | 5-8 Kgf |
Workbench Dimension | 680×310mm |
The max. binding width | 520mm |
Power | (1ph)220V 50/60HZ(other voltage on request) |
Net weight | 800Kg |
