· Reliable boards system work on stable,high precision machine body ,it can work on any line.
· Automatic stirring system for white ink and lacking ink alarming system. Making sure non-stop working. Together with alarm function for ink shortage.
· White ink channel on or off optional and output percentage adjustable, make printing more vividly and saturation.
· Carriage height could reach to 24cm; And it can work on 3 heads by varnish+white+color, Print speed faster, and control easier.
· Highly integration control software with non-stop working function, easy to read and add print file during printing.
· Support for multiple printing on same picture by one time, fit for most special produciton request.
· Reliable boards system work on stable,high precision machine body ,it can work on any line.
· Automatic stirring system for white ink and lacking ink alarming system. Making sure non-stop working. Together with alarm function for ink shortage.
· White ink channel on or off optional and output percentage adjustable, make printing more vividly and saturation.
· Carriage height could reach to 24cm; And it can work on 3 heads by varnish+white+color, Print speed faster, and control easier.
· Highly integration control software with non-stop working function, easy to read and add print file during printing.
· Support for multiple printing on same picture by one time, fit for most special produciton request.
Model | LQ-MD 3040A/B | LQ-MD 4060A/B | ||
Printhead number | 1pc/ 2pcs | 1pc/ 2pcs | ||
Max printing head | 15cm | |||
Max printing size | 40×30cm | 40×60cm | ||
Optional printing color | 4 color+W+V, 4 color+W,4 color+V, 4 color only | |||
Speed | Double head | Single head | Double heads | Single head |
High quality | 120sec/page | 140sec/page | 120sec/page | 140sec/page |
Printing material | Glass, Tile, Acrylic, PP, Metal, Wood, Stone, Rotary material | |||
Rip software | Ultra print/ Maintop/ Photoprint | |||
Picture mode | PSD/ TIFF/ BMP/ EPS/ JPG | |||
Environment | 25-30℃, 50% humidity, clean | |||
Computer system | Windows XP/ Windows7/ Windows10 | |||
Machine size | 820×620×520mm | 920×850×550mm | ||
Package size | 900×700×600mm | 1220×950×660mm | ||
Machine weight | Net. 55kg/ Gross.80kg | Net. 85kg/ Gross.110kg |
