Ink type | Black solvent dye ink |
Print cartridge type | Funai Zion |
Resolution | Up to 300dpi |
Nozzle count | 320 |
Print swath | 13.5mm |
Firing voltage | 9.6V |
Pre-fire pulse width | 470ns |
Delay | 1200ns |
Main-fire pulse width | 1300ns |
Pulse warming | OFF |
Decap time | Up to 10min |
Drying time | 4-5s at 300×200dpi |
Throw distance | Up to 8mm, recommended 5mm |
Average delivered ink | 40ml |
Average drop volume | 45pl |
Operating conditions | 15-35℃, 35 to 80% RH |
Shipping/ storage temperature | 5 to 30℃ |
Shelf life | 9 months from filling date |
