LQ-3201 Slitting Machine

LQ-3201 automatic slitting machine is the auxiliary products of automatic die cutting machine. It has functions of automatic meter counting, number counting ,The unwinding is controlled by photoelectric eyes .The structure is compact with high speed ,high efficiency ,easy and steady operation
Availability:
Quantity:
Inquire Add to Basket

PDF Export
LQ-3201 Slitting Machine
LQ-3201 Slitting Machine
LQ-3201 Slitting Machine

  • LQ-3201

  • UPG

LQ-3201 automatic slitting machine is the auxiliary products of automatic die cutting machine. It has functions of automatic meter counting, number counting ,The unwinding is controlled by photoelectric eyes .The structure is compact with high speed ,high efficiency ,easy and steady operation




Slitting   Speed

120m/min

Max.Web   Width

320mm

Max.Unwinding Diameter

550mm

Max.Rewinding   Diameter

300mm

Precision   of Slitting

±0.15mm

Dimension(L*W*H)

1100*1300*1700mm

Weight

500KG

Voltage

220V   1phase




Model

LQ-3201

Frequency   transformer

Schneider

Manual   tension for unwinding

ZXT(China)

Manual   tension for rewinding

ZXT(China)

Magnetic Clutch

Guanhua(China)

Magnetic   brake

Guanhua(China)

Web   Guiding motor

China

Counting

SICK from Germany

Photoelectric

CNBDL

Sensor

Shielded sensor

Power   Switch

Schneider

Pneumatic   Switch

Schneider

Switch

CHNT(China)

Shaft   3inch

2   pcs

Shaft   1.5inch turret

2pcs

Rotary   balde

7   set
