Synchro-Cut Servo Motor Driven Sheeter

Quantity:
  • 1400/1650 SK Sheeter
  • UPG


image1image2image3image4image5image6

image7image8


Specifications:

Model: speedwell 1400 SK Sheeter 1650 SK Sheeter
Web width range 400-1400mm (16”-55”) 400-1650mm (16”-64”)
Sheet length range 460-1450mm (18”-57”) 460-1450mm (18”-57”)
Pile height including
pallet
  1300mm
   51”
   1300mm
     51”
Gross pile weight   2000kg (4400lbs)   2000kg(4400lbs)
Mechanical linear speed   300m/min   300m/min
Knife load-cross cutter  Up to 800gsm Up to 800gsm
Sheet squareness  +/-0.5mm  +/-0.5mm
Sheet length accuracy  +/-0.5mm  +/-0.5mm
Pre-printed roll   n/a   n/a
Approx.footprint area 14500x4500x2300mm 14500x4750x2300mm
