LQ-DS
UPG
Features:
Double shafts crusher adopts imported material blade;
PLC control system, automatic overload reversal, with advantage in low speed, low noise, etc;
Knife specification and type are decided by the material type;
Application: suitable for shredder plastic, metal, wood, waste paper, garbage, etc. Materials can be recycled and compressed directly after shredding.
Features:
Double shafts crusher adopts imported material blade;
PLC control system, automatic overload reversal, with advantage in low speed, low noise, etc;
Knife specification and type are decided by the material type;
Application: suitable for shredder plastic, metal, wood, waste paper, garbage, etc. Materials can be recycled and compressed directly after shredding.
Model | LQ-DS600 | LQ-DS800 | LQ-DS1000 | LQ-DS1500 |
Power(Kw/Hp) | 7.5+7.5/10+10 | 15+15/20+20 | 18.5+18.5/25+25 | 55+55/73+73 |
Rotor blades(Pcs) | 20 | 20 | 20 | 30 |
Rotate speed(RPM) | 15-24 | 15-24 | 15-24 | 15-24 |
Machine size(L*W*H)mm | 2800*1300*1850 | 3200*1300*1950 | 3200*1300*2000 | 4500*1500*2400 |
Machine weight(Kg) | 2300 | 3300 | 5000 | 10000 |
Model | LQ-DS600 | LQ-DS800 | LQ-DS1000 | LQ-DS1500 |
Power(Kw/Hp) | 7.5+7.5/10+10 | 15+15/20+20 | 18.5+18.5/25+25 | 55+55/73+73 |
Rotor blades(Pcs) | 20 | 20 | 20 | 30 |
Rotate speed(RPM) | 15-24 | 15-24 | 15-24 | 15-24 |
Machine size(L*W*H)mm | 2800*1300*1850 | 3200*1300*1950 | 3200*1300*2000 | 4500*1500*2400 |
Machine weight(Kg) | 2300 | 3300 | 5000 | 10000 |
