LQ-GI FLEXO PLATE

UPG flexo plate, the next generation sheet photopolymer which is specifically designed to address all direct print corrugated board requirements. UPG flexo plate sheet photopolymer provides excellent solids coverage, while its low tack and high resilience offer long and clean press runs.

Quantity:
  • LQ-GI
  • UPG
  • 3701302500

Brief Introduction

UPG flexo plate, the next generation sheet photopolymer which is specifically designed to address all direct print corrugated board requirements. UPG flexo plate sheet photopolymer provides excellent solids coverage, while its low tack and high resilience offer long and clean press runs.


Main Features:

  • Holds the finest detail without the need to back mask

  • Quick wash out

  • Requires minimum impression settings, giving goodbalance between solids and screens

  • No cupping allows for uniform impression at all process speeds

  • Good resistance towards mechanical impacts and extremely durable

  • Compatible with water and alcohol-based inks containing up to 25% acetate

  • Suitable for corrugated post printing and other paper substrates


Hardness (Shore Å)112 mil/2.84 mm:40
155 mil/3.94 mm:37
217 mil/5.5mm: 35
250 mil/6.35 mm:34
278 mil/7.0 mm:34
Image reproduction3 – 95%   100lpi
Minimum isolated line0.20 mm
Minimum isolated dot0.25 mm
Max size52×80/1320×2032 inch/mm
