LQ8060T15
UPG
The small vertical model has a wide range of applications and can be used for recycling and baling of waste paper, cartons, plastic films, PET bottles, leather, and some fibers.
* Adopt integrated design, button centralized control, it can realize a variety of working methods.
* Independent feed opening and automatic bag-out device, convenient and simple operation, interlocking device installed at the feed opening, safe and reliable.
* Adopt British imported seals to improve the service life of the oil cylinder.
* The oil pipe joints are connected in a tapered form without gaskets to avoid oil leakage
The small vertical model has a wide range of applications and can be used for recycling and baling of waste paper, cartons, plastic films, PET bottles, leather, and some fibers.
* Adopt integrated design, button centralized control, it can realize a variety of working methods.
* Independent feed opening and automatic bag-out device, convenient and simple operation, interlocking device installed at the feed opening, safe and reliable.
* Adopt British imported seals to improve the service life of the oil cylinder.
* The oil pipe joints are connected in a tapered form without gaskets to avoid oil leakage
Model | LQ8060T15 | LQ8060T20 | LQ8060T30 |
Hydraulic Power(Ton) | 15 | 20 | 30 |
Bale Size(L*W*H)mm | 800*600*(400-800) | 800*600*(400-800) | 800*600*(400-800) |
Feed opening Size(L*H)mm | 800*450 | 800*450 | 800*450 |
Capability(Bales/Hr) | 4-7 | 4-7 | 4-7 |
Bale Weight(Kg) | 50-120 | 80-120 | 100-150 |
Voltage(Can be Customized)(V/Hz) | 380V/50Hz | 380V/50Hz | 380V/50Hz |
Power(Kw/Hp) | 3Kw/4Hp | 4Kw/5.5Hp | 5.5Kw/7.5Hp |
Machine Size(L*W*H)mm | 1280*900*2870 | 1280*900*3020 | 1280*900*3050 |
Weight(Kg) | 850 | 1050 | 1200 |
Model | LQ8060T15 | LQ8060T20 | LQ8060T30 |
Hydraulic Power(Ton) | 15 | 20 | 30 |
Bale Size(L*W*H)mm | 800*600*(400-800) | 800*600*(400-800) | 800*600*(400-800) |
Feed opening Size(L*H)mm | 800*450 | 800*450 | 800*450 |
Capability(Bales/Hr) | 4-7 | 4-7 | 4-7 |
Bale Weight(Kg) | 50-120 | 80-120 | 100-150 |
Voltage(Can be Customized)(V/Hz) | 380V/50Hz | 380V/50Hz | 380V/50Hz |
Power(Kw/Hp) | 3Kw/4Hp | 4Kw/5.5Hp | 5.5Kw/7.5Hp |
Machine Size(L*W*H)mm | 1280*900*2870 | 1280*900*3020 | 1280*900*3050 |
Weight(Kg) | 850 | 1050 | 1200 |
